FOR AWNINGS

9047

Worm gear.
Ratio 7:1

Device suitable for Awnings

FOR AWNINGS

Worm gear.
Ratio 7:1

  • Case in powder-coated Zamak.
  • Crown in Zamak.
  • Screw worm in Duraluminium.
  • Eyelet in Nylon.
  • Floating on POM bearings.
  • Without stop.

Main characteristics

Code
Output torque (Nm)
Transmission
Reduction ratio
Stop
Output (mm)
Drive (mm)
Case colour / finish
Crown material
Casing collar
Holes on case (mm)
9047_P08CH05
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 7035
Zama
No
Ø6
9047_P08CH05F
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 7035
Zama
No
M6
9047BP08CH05
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 7035
Zama
Yes
Ø6
9047BP08CH05F
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 7035
Zama
Yes
M6
9047_P12CH05
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 7035
Zama
No
Ø6
9047_P12CH05F
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 7035
Zama
No
M6
9047BP12CH05
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 7035
Zama
Yes
Ø6
9047BP12CH05F
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 7035
Zama
Yes
M6
9047_P08CH03
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 1013
Zama
No
Ø6
9047_P12CH03
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 1013
Zama
No
Ø6
9047BP08CH03
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 1013
Zama
Yes
Ø6
9047_P08CH02
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 9010
Zama
No
Ø6
9047_P08CH02F
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 9010
Zama
No
M6
9047_P12CH02
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 9010
Zama
No
Ø6
9047_P12CH02F
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 9010
Zama
No
M6
9047BP08CH02
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 9010
Zama
Yes
Ø6
9047BP08CH02F
7.4
Worm gear
7:1
No
Q13
Eyelet 80
RAL 9010
Zama
Yes
M6
9047BP12CH02
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 9010
Zama
Yes
Ø6
9047BP12CH02F
7.4
Worm gear
7:1
No
Q13
Eyelet 120
RAL 9010
Zama
Yes
M6
